Introducing KubeStash v2026.4.27

We are pleased to announce the release of KubeStash v2026.4.27 . This release delivers secure and seamless backup & restore across the KubeStash ecosystem, with major improvements for credential-less operation on AWS and Azure. You can check out the full changelog HERE . In this post, we’ll highlight the major changes.

Quick highlights

• Extended AWS credential-less mode with dynamically created IAM roles to overcome the trust policy character quota limit on production clusters.
• Added job suspension via webhook to prevent backup jobs from running before AWS IAM permissions are fully propagated.
• Introduced Azure credential-less backup & restore on AKS using Azure’s Identity Binding feature to overcome the 20 federated credential limit.
• Manually fetch and inject AWS credentials in IRSA-enabled clusters to ensure restic can access S3 reliably.
• Fixed BackupSession status remaining stuck in Running state on retention job failure.

What’s New

Overcoming AWS IAM Trust Policy Quota with Seed Roles

KubeStash’s AWS credential-less mode uses IRSA (IAM Roles for Service Accounts) to grant backup jobs access to S3 without credentials. However, AWS IAM Role trust policies have a quota of 2048 characters , which allows only roughly ~20 service accounts per trust policy. In a production cluster with hundreds of databases—each with its own BackupConfiguration—this limit is quickly exhausted, since every scheduled backup job creates a distinct service account.

To overcome this constraint, KubeStash now creates IAM roles dynamically using a seed role as a template. The seed role carries the cluster’s OIDC provider configuration and permission set; each derived role gets a numeric suffix (e.g., kubestash-selfhost-i) and holds a small batch of service accounts in its trust policy.

Seed role trust policy example

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Federated": "arn:aws:iam::748392615204:oidc-provider/oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E"
      },
      "Action": "sts:AssumeRoleWithWebIdentity",
      "Condition": {
        "StringLike": {
          "oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E:sub": [
            "system:serviceaccount:kubestash:kubestash-operator-operator"
          ],
          "oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E:aud": "sts.amazonaws.com"
        }
      }
    }
  ]
}

Derived role trust policy example (the -i suffix indicates the i-th dynamically created role from the seed)

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Principal": {
        "Federated": "arn:aws:iam::748392615204:oidc-provider/oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E"
      },
      "Action": "sts:AssumeRoleWithWebIdentity",
      "Condition": {
        "StringLike": {
          "oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E:sub": [
            "system:serviceaccount:demo:pg-backup-1772006820",
            "system:serviceaccount:demo:mongo-backup-177300719"
          ],
          "oidc.eks.us-east-1.amazonaws.com/id/9F3A7C1B5D8E42A6C91E0F2B4A7D6C8E:aud": "sts.amazonaws.com"
        }
      }
    }
  ]
}

How it works

1. The KubeStash operator annotates each backup job’s service account with go.klusters.dev/seed-role-name, pointing to the seed role ARN (e.g., go.klusters.dev/seed-role-name: arn:aws:iam::748392615204:role/kubestash-selfhost).
2. The credential manager checks whether any existing derived role has capacity to accommodate the new service account.
3. If none does, it creates a new derived role cloned from the seed role—same OIDC provider and permissions—with a numeric suffix (e.g., kubestash-selfhost-7).
4. The new service account is added to that derived role’s trust policy and annotated with the assigned role ARN (e.g., eks.amazonaws.com/role-arn: arn:aws:iam::748392615204:role/kubestash-selfhost-7).
5. By default, at most 100 derived roles can be created from a single seed; this ceiling is configurable via the roleCreationLimit flag.

This strategy scales credential-less backup to production clusters with hundreds of BackupConfiguration resources without hitting the trust policy character quota.

PR Link: https://github.com/kluster-api/aws-credential-manager/pull/14

Job Suspension

The AWS credential manager watches all jobs created by KubeStash (identified by the "app.kubernetes.io/managed-by": "kubestash.com" label). If a job’s service account does not yet have the required IAM permissions at the time the job is created, the job is suspended via a webhook. Once the service account is granted the proper permissions, the job is automatically unsuspended and proceeds normally.

This prevents a race condition where a backup job starts executing before its IAM role has been fully provisioned.

PR Link: https://github.com/kubestash/kubestash/pull/343

Azure Credential-less Mode

KubeStash now supports credential-less backup & restore on AKS clusters using Azure’s Identity Binding feature—an extension of Azure Workload Identity introduced specifically to address the 20 federated credential limit .

With this mode, no explicit secret needs to be referenced in the BackupStorage:

Sample BackupStorage

apiVersion: storage.kubestash.com/v1alpha1
kind: BackupStorage
metadata:
  name: azure-storage
  namespace: default
spec:
  storage:
    provider: azure
    azure:
      storageAccount: nipunstorageaccount7620
      container: container7620
      prefix: nipun-identity-binding
  usagePolicy:
    allowedNamespaces:
      from: All
  default: true
  deletionPolicy: WipeOut

Notice that no secretName is specified—KubeStash resolves Azure Blob Storage credentials through the managed identity.

How it works

For any job that needs to access Azure Blob Storage, KubeStash adds the following annotations to the job and its service account:

klusters.dev/azure-mi-name: "<MI_NAME>"
klusters.dev/azure-rg-name: "<RESOURCE_GROUP>"
klusters.dev/azure-subscription-id: "<SUBSCRIPTION_ID>"

The azure-credential-manager then:

1. Watches service accounts that carry the above annotations.
2. Annotates the service account with the managed identity’s tenant ID and client ID:

azure.workload.identity/client-id: <MI_CLIENT_ID>
azure.workload.identity/tenant-id: <MI_TENANT_ID>

3. Adds the required labels and annotations to job pod templates for identity binding:

labels:
  azure.workload.identity/use: "true"
annotations:
  azure.workload.identity/use-identity-binding: "true"

4. Configures RBAC to grant the service account permission to use the managed identity:

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: use-mi-<MI_CLIENT_ID>
rules:
  - verbs: ["use-managed-identity"]
    apiGroups: ["cid.wi.aks.azure.com"]
    resources: ["<MI_CLIENT_ID>"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: use-mi-<MI_CLIENT_ID>
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: use-mi-<MI_CLIENT_ID>
subjects:
  - kind: ServiceAccount
    name: pg-backup-1772006820
    namespace: demo

The backup pod will have the following Azure environment variables and projected token volume mounts injected automatically:

$ kubectl get pod <kubestash-operator-pod> -n <kubestash-namespace> -o yaml | grep AZURE
      - name: AZURE_CLIENT_ID
      - name: AZURE_TENANT_ID
      - name: AZURE_FEDERATED_TOKEN_FILE
      - name: AZURE_AUTHORITY_HOST
      - name: AZURE_KUBERNETES_TOKEN_PROXY
      - name: AZURE_KUBERNETES_SNI_NAME
      - name: AZURE_KUBERNETES_CA_FILE

PR Link: https://github.com/kluster-api/azure-credential-manager/pull/1

Bug Fix and Improvements

Manually Set AWS Credentials in IRSA-enabled Clusters

In IRSA-enabled clusters, restic may fail to fetch credentials from the service account token, causing errors like: s3.getCredentials: no credentials found.

Since restic relies on minio-go-client instead of the official AWS SDK, fixing this at the source is complex. As a workaround, we now manually retrieve and inject AWS credentials (with retries) so restic can reliably access S3.

PR Link: https://github.com/kubestash/apimachinery/commits/master/

Fix BackupSession Status Running

BackupSession could previously remain stuck in the Running state if the retention policy job failed. Now, on retention job failure, a condition is set with an appropriate message, allowing the BackupSession controller to correctly mark the status as Failed.

PR Link: https://github.com/kubestash/kubestash/pull/353

What Next?

Please try the latest release and give us your valuable feedback.

• If you want to install KubeStash in a clean cluster, please follow the installation instruction from HERE .
• If you want to upgrade KubeStash from a previous version, please follow the upgrade instruction from HERE .

Support

To speak with us, please leave a message on our website .
