Chaos Engineering KubeDB MariaDB on Kubernetes, Testing Galera Cluster & Standard Replication Resilience

Overview

We conducted 40+ chaos experiments across 2 MariaDB topologies (Galera Cluster and MariaDB Replication with MaxScale) on KubeDB-managed 3-node clusters. The goal: validate that KubeDB MariaDB delivers zero data loss, automatic failover, and self-healing recovery under realistic failure conditions with production-level write loads.

The result: All experiments passed with zero data loss. Both topologies recovered automatically from every pod, stress, network, IO-fault, time, and DNS scenario tested.

This post summarizes the methodology, results, and key findings from comprehensive chaos testing of KubeDB MariaDB.

Why Chaos Testing?

Running databases on Kubernetes introduces failure modes that traditional infrastructure does not have — pods can be evicted, nodes can go down, network policies can partition traffic, and resource limits can trigger OOMKills at any time. Chaos engineering deliberately injects these failures to verify that the system recovers correctly before they happen in production.

For a MariaDB cluster managed by KubeDB (Galera Cluster or Replication with MaxScale), we needed to answer:

Does the cluster lose data when a primary/master is killed mid-transaction?
Does automatic failover work under network partitions?
Can the cluster self-heal after a full outage with no manual intervention?
Are replication GTIDs consistent across all nodes after recovery?
Does the cluster survive combined failures (CPU + memory + load simultaneously)?

Setup Guide

Step 1: Create a kind Cluster

We used kind (Kubernetes IN Docker) as our local Kubernetes cluster. Follow the kind installation guide to install it, then create a cluster:

kind create cluster --name chaos-test

Step 2: Install KubeDB

Install KubeDB operator using Helm:

helm install kubedb oci://ghcr.io/appscode-charts/kubedb \
  --version v2026.2.26 \
  --namespace kubedb --create-namespace \
  --set-file global.license=/path/to/license.txt \
  --wait --burst-limit=10000 --debug

Step 3: Install Chaos Mesh

Install Chaos Mesh for fault injection:

helm repo add chaos-mesh https://charts.chaos-mesh.org
helm repo update chaos-mesh

helm upgrade -i chaos-mesh chaos-mesh/chaos-mesh \
  -n chaos-mesh --create-namespace \
  --set dashboard.create=true \
  --set dashboard.securityMode=false \
  --set chaosDaemon.runtime=containerd \
  --set chaosDaemon.socketPath=/run/containerd/containerd.sock \
  --set chaosDaemon.privileged=true

Step 4: Deploy MariaDB Galera Cluster

Create the namespace:

kubectl create namespace demo

Important Notes on Database Status:
Ready — Database is fully operational. All pods are Synced.
Critical — Cluster has quorum but one or more nodes may be down or desynced.
NotReady — Cluster has lost quorum. No writes can be accepted.
You can read/write in your database in both Ready and Critical states. Even if your db is in Critical state, your uptime is not compromised.

Test Environment

Component	Details
Kubernetes	kind (local cluster)
KubeDB Version	2026.4.27
Cluster Topology	3-node Galera Cluster (all nodes read-write)
MariaDB Version	11.8.5
Storage	2Gi PVC per node (Durable, ReadWriteOnce)
Memory Limit	1.5Gi per MariaDB pod
CPU Request	500m per pod
Chaos Engine	Chaos Mesh
Load Generator	sysbench `oltp_read_write`, 4 tables x 50k rows, 4 threads
Baseline TPS	~1,039

All experiments were run under sustained sysbench read-write load to simulate production traffic during failures.

Create a High-Availability MariaDB Galera Cluster

First, we need to deploy a MariaDB cluster configured for High Availability. Unlike a Standalone instance, a Galera Cluster consists of 3 multi-master nodes that all accept reads and writes simultaneously. If any node fails, the remaining nodes continue serving traffic with zero downtime.

Save the following YAML as setup/kubedb-mariadb.yaml:

apiVersion: kubedb.com/v1
kind: MariaDB
metadata:
  name: md
  namespace: demo
spec:
  deletionPolicy: Delete
  replicas: 3
  storage:
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 2Gi
  storageType: Durable
  podTemplate:
    spec:
      containers:
        - name: mariadb
          resources:
            limits:
              memory: 1.5Gi
            requests:
              cpu: 500m
              memory: 1.5Gi
  topology:
    mode: GaleraCluster
  version: 11.8.5

Important Notes:
You can read/write in your database in both Ready and Critical states. So it means even if your db is in Critical state, your uptime is not compromised. Critical means one or more nodes are offline, but the remaining nodes have quorum and accept connections.
All the results/metrics shown in this blog are related to the chaos scenarios. In general, a Galera node recovery takes ~5-30 seconds with zero data loss, ensuring high availability and data safety.
Each MariaDB pod runs a KubeDB coordinator sidecar (md-coordinator container) alongside the mariadb container. The coordinator is the brain behind all recovery operations — it detects failures, triggers failovers, bootstraps clusters, and manages replication. This is what we are testing.

Now, create the namespace and apply the manifest:

kubectl create ns demo
kubectl apply -f setup/kubedb-mariadb.yaml

You can monitor the status until all pods are ready:

watch kubectl get mariadb,pods -n demo -L kubedb.com/role

See the database status is ready:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    68m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          68m   Primary
pod/md-1   2/2     Running   0          68m   Primary
pod/md-2   2/2     Running   0          68m   Primary

Note: In Galera Cluster, all nodes have role Primary because every node accepts reads and writes. This is different from MySQL Group Replication or PostgreSQL where you have a single primary and standbys.

Deploy sysbench Load Generator

apiVersion: apps/v1
kind: Deployment
metadata:
  name: sysbench-load
  namespace: demo
  labels:
    app: sysbench
spec:
  replicas: 1
  selector:
    matchLabels:
      app: sysbench
  template:
    metadata:
      labels:
        app: sysbench
    spec:
      containers:
        - name: sysbench
          image: perconalab/sysbench:latest
          command: ["/bin/sleep", "infinity"]
          resources:
            requests:
              cpu: "500m"
              memory: "512Mi"
            limits:
              cpu: "2"
              memory: "2Gi"
          env:
            - name: MYSQL_HOST
              value: "md.demo.svc.cluster.local"
            - name: MYSQL_PORT
              value: "3306"
            - name: MYSQL_USER
              value: "root"
            - name: MYSQL_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: md-auth
                  key: password
            - name: MYSQL_DB
              value: "sbtest"

kubectl apply -f sysbench.yaml

Prepare sysbench Tables

# Get the MariaDB root password
PASS=$(kubectl get secret md-auth -n demo -o jsonpath='{.data.password}' | base64 -d)

# Create the sbtest database
kubectl exec -n demo md-0 -c mariadb -- \
  mariadb -uroot -p"$PASS" -e "CREATE DATABASE IF NOT EXISTS sbtest;"

# Get the sysbench pod name
SBPOD=$(kubectl get pods -n demo -l app=sysbench -o jsonpath='{.items[0].metadata.name}')

# Prepare tables (4 tables x 50k rows)
kubectl exec -n demo $SBPOD -- sysbench oltp_read_write \
  --mysql-host=md --mysql-port=3306 \
  --mysql-user=root --mysql-password="$PASS" \
  --mysql-db=sbtest --tables=4 --table-size=50000 \
  --threads=4 prepare

Run sysbench During Chaos

kubectl exec -n demo $SBPOD -- sysbench oltp_read_write \
  --mysql-host=md --mysql-port=3306 \
  --mysql-user=root --mysql-password="$PASS" \
  --mysql-db=sbtest --tables=4 --table-size=50000 \
  --threads=4 --time=60 --report-interval=10 run

Galera Cluster Key Concepts

Unlike MySQL Group Replication which has a single primary and secondaries, MariaDB Galera Cluster is multi-master — all nodes accept reads and writes simultaneously. Key status variables:

Variable	Meaning
`wsrep_cluster_size`	Number of nodes in the cluster
`wsrep_cluster_status`	`Primary` = cluster has quorum and is operational
`wsrep_local_state_comment`	`Synced` / `Joined` / `Donor` / `Desynced`
`wsrep_ready`	`ON` = node accepts queries
`wsrep_connected`	`ON` = node connected to cluster
`wsrep_flow_control_paused`	Fraction of time paused for flow control (0.0 = healthy)

Important Notes on Database Status:
Ready — Database is fully operational. All pods are Synced.
Critical — Cluster has quorum but one or more nodes may be down or desynced.
NotReady — Cluster has lost quorum. No writes can be accepted.
You can read/write in your database in both Ready and Critical states. Even if your db is in Critical state, your uptime is not compromised.

Chaos Testing

We will run chaos experiments to see how our Galera cluster behaves under failure scenarios. We use sysbench to simulate high read-write load during each experiment.

Verify Cluster is Ready

Before starting chaos experiments, verify the cluster is healthy:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    68m

NAME                                 READY   STATUS    RESTARTS      AGE    ROLE
pod/md-0                             2/2     Running   1 (34m ago)   68m    Primary
pod/md-1                             2/2     Running   0             12m    Primary
pod/md-2                             2/2     Running   0             68m    Primary

Note: In Galera Cluster, all nodes have role Primary because every node accepts reads and writes.

Inspect the Galera cluster status:

➤ kubectl exec -n demo md-0 -c mariadb -- \
    mariadb -uroot -p"$PASS" -e "SHOW GLOBAL STATUS WHERE Variable_name IN (
      'wsrep_cluster_size','wsrep_cluster_status',
      'wsrep_local_state_comment','wsrep_ready',
      'wsrep_connected','wsrep_flow_control_paused');"
Variable_name              Value
wsrep_flow_control_paused  0
wsrep_local_state_comment  Synced
wsrep_cluster_size         3
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

All 3 nodes Synced, cluster_size=3, wsrep_ready=ON. With the cluster ready and sysbench tables prepared, we are ready to run chaos experiments.

Chaos#1: Kill a Pod

We kill one MariaDB pod and see how fast the Galera cluster recovers. In Galera, since all nodes are equal, killing any node should be handled gracefully.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: mariadb-primary-pod-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  gracePeriod: 0

What this chaos does: Terminates one MariaDB pod abruptly with grace-period=0, forcing the remaining 2 nodes to handle all traffic while the killed pod recovers.

Expected behavior: One pod killed → cluster briefly Critical (2/3 members left) → killed pod recreated by StatefulSet → rejoins via IST (Incremental State Transfer) → wsrep_cluster_size returns to 3, all nodes Synced → cluster Ready. Zero data loss — all 25 tracking rows and table checksums consistent.
Actual result: md-0 killed (age=8s after recreation). Auto-rejoined via IST within ~5s. All 3 nodes Synced, wsrep_cluster_size=3. 25/25 tracking rows preserved, checksums match across all 3 nodes. Post-recovery TPS 1061 (back to baseline). PASS.

Before running:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    68m

NAME       READY   STATUS    RESTARTS      AGE   ROLE
pod/md-0   2/2     Running   1 (34m ago)   68m   Primary
pod/md-1   2/2     Running   0             12m   Primary
pod/md-2   2/2     Running   0             68m   Primary

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/pod-kill-primary.yaml
podchaos.chaos-mesh.org/mariadb-primary-pod-kill created

Within seconds, one pod is killed and recreated. The database goes Critical briefly:

➤ kubectl get mariadb,pods -n demo
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    68m

NAME       READY   STATUS    RESTARTS   AGE
pod/md-0   2/2     Running   0          8s
pod/md-1   2/2     Running   0          12m
pod/md-2   2/2     Running   0          68m

md-0 was killed and recreated (age=8s). After about 5 seconds, the pod rejoins the Galera cluster and syncs via IST (Incremental State Transfer). Check Galera status:

➤ SHOW GLOBAL STATUS WHERE Variable_name IN ('wsrep_cluster_size','wsrep_cluster_status',
    'wsrep_local_state_comment','wsrep_ready','wsrep_connected');

md-0:
Variable_name              Value
wsrep_local_state_comment  Synced
wsrep_cluster_size         3
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

md-1:
Variable_name              Value
wsrep_local_state_comment  Synced
wsrep_cluster_size         3
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

md-2:
Variable_name              Value
wsrep_local_state_comment  Synced
wsrep_cluster_size         3
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

All 3 nodes Synced. Run sysbench to verify the cluster is fully operational:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1063.05 qps: 21272.82 (r/w/o: 14891.32/2327.87/4053.63) lat (ms,95%): 5.00 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1059.67 qps: 21198.98 (r/w/o: 14840.36/2343.15/4015.46) lat (ms,95%): 4.91 err/s: 0.20 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1060.19 qps: 21202.99 (r/w/o: 14841.86/2407.58/3953.56) lat (ms,95%): 4.91 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        15919  (1060.99 per sec.)
    queries:                             318397 (21220.87 per sec.)
    ignored errors:                      1      (0.07 per sec.)
    reconnects:                          0      (0.00 per sec.)

Verify data integrity:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=2941988609, sbtest2=1454430013, sbtest3=496174579, sbtest4=1322761405
md-1: sbtest1=2941988609, sbtest2=1454430013, sbtest3=496174579, sbtest4=1322761405
md-2: sbtest1=2941988609, sbtest2=1454430013, sbtest3=496174579, sbtest4=1322761405

Result: PASS — Zero data loss. Pod recreated in ~5 seconds, auto-rejoined via IST. All 25 tracking rows preserved, checksums match across all 3 nodes. Post-recovery throughput: 1061 TPS (back to baseline).

Clean up:

➤ kubectl delete -f 1-single-experiments/pod-kill-primary.yaml
podchaos.chaos-mesh.org "mariadb-primary-pod-kill" deleted

Chaos#2: OOMKill (Memory Stress)

We stress-test memory on one node to see if the cluster survives under extreme memory pressure.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: mariadb-primary-memory-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  stressors:
    memory:
      workers: 2
      size: "1400MB"
  duration: "10m"

What this chaos does: Allocates 1400MB of extra memory on one pod. With MariaDB’s memory usage, this approaches the 1.5Gi limit.

Expected behavior: Memory stress pushes pod near 1.5Gi limit → either (a) pod OOMKilled → recreated → rejoins via IST, or (b) survives with degraded performance. Cluster stays operational at ≥ 2 nodes throughout. Zero data loss either way.
Actual result: MariaDB survived 1400MB stress trigger OOMKill. mariadb container of md-0 got restarted and joined the cluster again. Cluster ran at 1050 TPS (no degradation). 25/25 tracking rows preserved, checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/stress-memory-primary.yaml
stresschaos.chaos-mesh.org/mariadb-primary-memory-stress created

After 20 seconds, check pods — md-0 get OOMKill triggered:

➤ kubectl get mariadb,pods -n demo
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    76m

NAME       READY   STATUS    RESTARTS   AGE
pod/md-0   2/2     Running   1 (4m ago)          7m54s
pod/md-1   2/2     Running   0          20m
pod/md-2   2/2     Running   0          76m

Run sysbench during stress:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1051.05 qps: 21032.31 (r/w/o: 14723.04/2446.84/3862.43) lat (ms,95%): 4.91 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1046.48 qps: 20930.60 (r/w/o: 14652.32/2489.19/3789.09) lat (ms,95%): 5.00 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1052.99 qps: 21064.27 (r/w/o: 14745.71/2533.78/3784.78) lat (ms,95%): 4.91 err/s: 0.20 reconn/s: 0.00

SQL statistics:
    transactions:                        15757  (1050.21 per sec.)
    queries:                             315156 (21005.21 per sec.)
    ignored errors:                      1      (0.07 per sec.)
    reconnects:                          0      (0.00 per sec.)

Verify data integrity:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3400554968, sbtest2=1909458598
md-1: sbtest1=3400554968, sbtest2=1909458598
md-2: sbtest1=3400554968, sbtest2=1909458598

Result: PASS — MariaDB survived memory stress with OOMKill. Cluster fully operational at 1050 TPS (no degradation). All 25 tracking rows preserved, checksums match.

Clean up:

➤ kubectl delete -f 1-single-experiments/stress-memory-primary.yaml
stresschaos.chaos-mesh.org "mariadb-primary-memory-stress" deleted

Chaos#3: Network Partition

We isolate one Galera node from the other two for 2 minutes. This tests whether the remaining nodes maintain quorum and continue serving traffic, and whether the isolated node rejoins cleanly.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-primary-network-partition
  namespace: chaos-mesh
spec:
  action: partition
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  target:
    mode: all
    selector:
      namespaces:
        - demo
      labelSelectors:
        "kubedb.com/role": "Primary"
  direction: both
  duration: "2m"

What this chaos does: Creates a complete network partition between one node and the rest of the cluster for 2 minutes. The isolated node loses quorum and becomes non-Primary. The remaining 2 nodes maintain quorum and continue accepting writes.

Expected behavior: One node isolated → loses quorum, becomes non-Primary, stops accepting queries (no split-brain) → remaining 2 nodes keep quorum, continue serving reads/writes → after partition lifts, isolated node auto-rejoins and syncs. Zero data loss.
Actual result: md-2 isolated, went wsrep_cluster_size=1, non-Primary, wsrep_ready=OFF. md-0/md-1 kept quorum at wsrep_cluster_size=2, Primary. TPS actually increased from 1039 → 1430 (fewer nodes to certify through). After partition lifted, md-2 auto-rejoined, all Synced. 25/25 tracking rows and checksums match. PASS.

Before running:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS   AGE
mariadb.kubedb.com/md   11.8.5    Ready    82m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          13m   Primary
pod/md-1   2/2     Running   0          25m   Primary
pod/md-2   2/2     Running   0          82m   Primary

➤ SHOW GLOBAL STATUS ...
wsrep_flow_control_paused  0.0277989
wsrep_local_state_comment  Synced
wsrep_cluster_size         3
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/network-partition-primary.yaml
networkchaos.chaos-mesh.org/mariadb-primary-network-partition created

Within ~15 seconds, the isolated node loses quorum. The database goes Critical:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    Critical   82m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          14m   Primary
pod/md-1   2/2     Running   0          26m   Primary
pod/md-2   2/2     Running   0          82m   non-Primary

Note: md-2 is non-Primary — it’s the isolated node. Let’s check Galera status from each node:

➤ # md-0 (in quorum):
wsrep_flow_control_paused  0.0257333
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

➤ # md-1 (in quorum):
wsrep_flow_control_paused  0.0209364
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

➤ # md-2 (ISOLATED):
wsrep_flow_control_paused  0.00670716
wsrep_local_state_comment  Initialized
wsrep_cluster_size         1
wsrep_cluster_status       non-Primary
wsrep_connected            ON
wsrep_ready                OFF

The isolated node (md-2) shows wsrep_cluster_size=1, wsrep_cluster_status=non-Primary, wsrep_ready=OFF — it cannot accept queries. The remaining 2 nodes still have quorum (wsrep_cluster_status=Primary) and accept both reads and writes.

Run sysbench during the partition:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1435.24 qps: 28715.89 (r/w/o: 20102.42/3503.22/5110.25) lat (ms,95%): 3.49 err/s: 0.20 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1437.64 qps: 28756.01 (r/w/o: 20129.37/3626.70/4999.94) lat (ms,95%): 3.43 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1416.81 qps: 28336.92 (r/w/o: 19836.08/3607.82/4893.02) lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        21453  (1429.89 per sec.)
    queries:                             429076 (28598.90 per sec.)
    ignored errors:                      1      (0.07 per sec.)
    reconnects:                          0      (0.00 per sec.)

TPS increased from 1039 to 1430 during partition — a 37% improvement! This is because with only 2 nodes, Galera certification has less overhead (fewer nodes to coordinate with).

After the 2-minute partition expires, the isolated node automatically rejoins:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS   AGE
mariadb.kubedb.com/md   11.8.5    Ready    85m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          17m   Primary
pod/md-1   2/2     Running   0          29m   Primary
pod/md-2   2/2     Running   0          85m   Primary

All 3 nodes back to Primary, cluster Ready. Verify:

➤ # Galera status — all Synced
md-0: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0.0208
md-1: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0.0186
md-2: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0.0064

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3192592587, sbtest2=1620218475, sbtest3=827673677, sbtest4=2199205073
md-1: sbtest1=3192592587, sbtest2=1620218475, sbtest3=827673677, sbtest4=2199205073
md-2: sbtest1=3192592587, sbtest2=1620218475, sbtest3=827673677, sbtest4=2199205073

Result: PASS — Network partition handled correctly. Isolated node became non-Primary and stopped accepting queries (no split-brain). Remaining 2 nodes maintained quorum at 1430 TPS. After partition expired, isolated node auto-rejoined and synced. Zero data loss — all 25 tracking rows preserved, checksums match.

Clean up:

➤ kubectl delete -f 1-single-experiments/network-partition-primary.yaml
networkchaos.chaos-mesh.org "mariadb-primary-network-partition" deleted

Chaos#4: IO Latency (100ms)

We inject 100ms latency on all disk operations on one node. This simulates degraded storage — a common issue with cloud block storage or overloaded disk controllers.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: mariadb-primary-io-latency
  namespace: chaos-mesh
spec:
  action: latency
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  volumePath: "/var/lib/mysql"
  path: "/**"
  delay: "100ms"
  percent: 100
  duration: "3m"

What this chaos does: Adds 100ms delay to every disk read/write on /var/lib/mysql for one node. This makes every InnoDB flush, WAL write, and data page read significantly slower.

Expected behavior: 100ms delay on every I/O → affected node becomes unresponsive → Galera flow control expels it (wsrep_cluster_size drops to 2 on remaining nodes) → the 2 healthy nodes keep serving writes → after chaos ends, expelled node auto-recovers and rejoins via IST. Zero data loss.
Actual result: md-1 became unreachable (socket errors). Remaining 2 nodes showed wsrep_cluster_size=2, served 1450 TPS with zero errors. After chaos, md-1 auto-rejoined, all 3 Synced. 25/25 tracking rows preserved, checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/io-latency-primary.yaml
iochaos.chaos-mesh.org/mariadb-primary-io-latency created

After ~10 seconds, the affected node (md-1) becomes completely unresponsive — MariaDB cannot handle 100ms latency on every disk operation:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS   AGE
mariadb.kubedb.com/md   11.8.5    Ready    88m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          19m   Primary
pod/md-1   2/2     Running   0          32m   Primary
pod/md-2   2/2     Running   0          88m   Primary

The pod shows Running/Ready (Kubernetes doesn’t know MariaDB inside is frozen), but the Galera cluster has already expelled the node:

➤ # md-0 (healthy):
wsrep_flow_control_paused  0.0189172
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

➤ # md-1 (IO latency target):
ERROR 2002 (HY000): Can't connect to local server through socket '/run/mysqld/mysqld.sock' (111)

➤ # md-2 (healthy):
wsrep_flow_control_paused  0.00631477
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_connected            ON
wsrep_ready                ON

The affected node is completely unreachable — wsrep_cluster_size=2 on the healthy nodes confirms Galera expelled it. Run sysbench against the 2 remaining nodes:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1452.19 qps: 29057.21 (r/w/o: 20341.06/3789.65/4926.49) lat (ms,95%): 3.36 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1456.70 qps: 29129.26 (r/w/o: 20390.44/3873.07/4865.74) lat (ms,95%): 3.30 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1440.25 qps: 28803.66 (r/w/o: 20162.34/3885.60/4755.71) lat (ms,95%): 3.43 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        21750  (1449.63 per sec.)
    queries:                             435000 (28992.63 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

1450 TPS on 2 nodes, zero errors. After the 3-minute IO latency expires, the affected node auto-recovers and rejoins:

➤ kubectl get mariadb -n demo md
NAME   VERSION   STATUS   AGE
md     11.8.5    Ready    94m

➤ # All nodes recovered:
md-0: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0.0145
md-1: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0
md-2: wsrep_cluster_size=3, Synced, wsrep_ready=ON, wsrep_flow_control_paused=0.0059

Verify data integrity:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3774570434, sbtest2=107955818, sbtest3=4222587866, sbtest4=2113239503
md-1: sbtest1=3774570434, sbtest2=107955818, sbtest3=4222587866, sbtest4=2113239503
md-2: sbtest1=3774570434, sbtest2=107955818, sbtest3=4222587866, sbtest4=2113239503

Result: PASS — IO latency caused the affected node to become unresponsive and expelled from Galera. The remaining 2 nodes continued serving 1450 TPS with zero errors. After chaos expired, the affected node auto-rejoined via IST. Zero data loss — all checksums match.

Clean up:

➤ kubectl delete -f 1-single-experiments/io-latency-primary.yaml
iochaos.chaos-mesh.org "mariadb-primary-io-latency" deleted

Chaos#5: Network Latency (1s)

We inject 1 second network latency between one node and all others. This tests how Galera certification handles slow cross-node communication — a common scenario with cross-region deployments or degraded network links.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-replication-latency
  namespace: chaos-mesh
spec:
  action: delay
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  target:
    mode: all
    selector:
      namespaces:
        - demo
      labelSelectors:
        "app.kubernetes.io/instance": "md"
        "kubedb.com/role": "Primary"
  delay:
    latency: "1s"
    jitter: "50ms"
  duration: "10m"
  direction: both

What this chaos does: Adds 1 second latency (+ 50ms jitter) between one node and all other cluster nodes. Every Galera certification message must wait 1 second each way.

Expected behavior: 1s latency on Galera traffic → synchronous certification requires ≥2s round trip → TPS collapses dramatically → but all 3 nodes stay Synced (1s is below the wsrep-timeout threshold) → no errors, no split-brain → TPS recovers after chaos. Zero data loss — this is Galera’s synchronous safety trade-off.
Actual result: TPS dropped from 1039 → 2.77 (99.7% reduction). 95p latency 2045ms (exactly one Paxos round-trip). All 3 nodes stayed Synced, 0 errors, 0 reconnects. 25/25 tracking rows and checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/network-latency-primary-to-replicas.yaml
networkchaos.chaos-mesh.org/mariadb-replication-latency created

Check Galera — all 3 nodes stay Synced (1s latency isn’t enough to trigger expulsion):

➤ # All nodes:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0136
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0058

But sysbench throughput is severely impacted:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 2.40 qps: 63.19 (r/w/o: 44.79/8.40/10.00) lat (ms,95%): 1938.16 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 2.80 qps: 56.00 (r/w/o: 39.20/7.80/9.00) lat (ms,95%): 1869.60 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 3.00 qps: 60.00 (r/w/o: 42.00/7.00/11.00) lat (ms,95%): 1973.38 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        45     (2.77 per sec.)
    queries:                             900    (55.49 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Latency (ms):
         min:                                  985.37
         avg:                                 1418.98
         max:                                 2090.38
         95th percentile:                     2045.74

TPS dropped from 1039 to 2.77 — a 99.7% reduction! This is because Galera uses synchronous replication: every write must be certified by all nodes. With 1s network latency, each certification round-trip takes ~2 seconds. The 95th percentile latency is 2045ms, confirming this.

However, note the key metrics: 0 errors, 0 reconnects. The cluster never broke — it just became extremely slow.

After removing the chaos, throughput returns to normal immediately. Verify data:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=620696091, sbtest2=702654982, sbtest3=2895801545, sbtest4=86505438
md-1: sbtest1=620696091, sbtest2=702654982, sbtest3=2895801545, sbtest4=86505438
md-2: sbtest1=620696091, sbtest2=702654982, sbtest3=2895801545, sbtest4=86505438

Result: PASS — 1s network latency caused severe throughput degradation (99.7% TPS drop) due to Galera’s synchronous certification, but the cluster remained operational with zero errors. No split-brain, no data loss. This is a key trade-off of synchronous replication: latency directly impacts throughput, but data safety is guaranteed.

Clean up:

➤ kubectl delete -f 1-single-experiments/network-latency-primary-to-replicas.yaml
networkchaos.chaos-mesh.org "mariadb-replication-latency" deleted

Chaos#6: CPU Stress (98%)

We apply 98% CPU stress on one node to see if the Galera cluster can handle a CPU-starved member.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: mariadb-primary-cpu-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  stressors:
    cpu:
      workers: 2
      load: 98
  duration: "5m"

What this chaos does: Consumes 98% CPU on one node using 2 stress workers. Tests whether the cluster maintains throughput and data consistency under extreme CPU pressure.

Expected behavior: 98% CPU stress on one node → MariaDB writes are mostly IO-bound, so impact should be modest → all 3 nodes stay Synced → TPS largely unchanged. Zero data loss.
Actual result: 1034 TPS (99.5% of baseline — negligible impact). All 3 nodes stayed Synced with wsrep_cluster_size=3. Zero errors, 25/25 tracking rows and checksums match. PASS — confirms Galera writes are IO-bound, not CPU-bound.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/stress-cpu-primary.yaml
stresschaos.chaos-mesh.org/mariadb-primary-cpu-stress created

All 3 nodes remain Synced:

➤ # Galera status during CPU stress:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0121
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0056

Run sysbench:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1033.26 qps: 20679.04 (r/w/o: 14476.27/2825.42/3377.35) lat (ms,95%): 5.18 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1026.65 qps: 20530.52 (r/w/o: 14371.44/2828.13/3330.95) lat (ms,95%): 5.09 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1041.79 qps: 20836.99 (r/w/o: 14586.25/2930.17/3320.57) lat (ms,95%): 5.00 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        15513  (1033.96 per sec.)
    queries:                             310260 (20679.19 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

1034 TPS — virtually no impact! MariaDB on Galera is largely IO-bound, not CPU-bound for write workloads.

Verify data:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3417352532, sbtest2=403445326
md-1: sbtest1=3417352532, sbtest2=403445326
md-2: sbtest1=3417352532, sbtest2=403445326

Result: PASS — 98% CPU stress had negligible impact on Galera cluster. 1034 TPS (99.5% of baseline). Zero errors, all nodes Synced throughout. MariaDB’s write path is IO-bound, not CPU-bound.

Clean up:

➤ kubectl delete -f 1-single-experiments/stress-cpu-primary.yaml
stresschaos.chaos-mesh.org "mariadb-primary-cpu-stress" deleted

Chaos#7: Packet Loss (30%)

We inject 30% packet loss across all cluster nodes. This simulates unreliable network infrastructure — congested switches, flaky NICs, or cloud provider network issues.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-cluster-packet-loss
  namespace: chaos-mesh
spec:
  action: loss
  mode: all
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
  loss:
    loss: "30"
    correlation: "25"
  duration: "5m"

What this chaos does: Drops 30% of all network packets on every cluster node with 25% correlation (burst losses). This affects both Galera replication traffic and client connections.

Expected behavior: 30% packet loss → TCP retransmissions slow Galera certification massively → TPS collapses → all 3 nodes stay Synced (losses don’t cross wsrep-timeout) → after chaos, TPS recovers. Zero data loss.
Actual result: TPS collapsed from 1039 → 1.32 (-99.9%). 95p latency 4.5s. All 3 nodes stayed Synced, wsrep_cluster_size=3, no expulsion, zero errors. 25/25 tracking rows and checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/packet-loss.yaml
networkchaos.chaos-mesh.org/mariadb-cluster-packet-loss created

All 3 nodes remain Synced — Galera handles retransmissions:

➤ # Galera status during 30% packet loss:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0124
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0077
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0064

But throughput is severely impacted due to TCP retransmissions and Galera certification delays:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1.00 qps: 28.99 (r/w/o: 21.80/3.20/4.00) lat (ms,95%): 4203.93 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1.60 qps: 33.40 (r/w/o: 23.40/4.40/5.60) lat (ms,95%): 5507.54 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 0.80 qps: 20.80 (r/w/o: 13.60/4.00/3.20) lat (ms,95%): 3326.55 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        21     (1.32 per sec.)
    queries:                             420    (26.40 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Latency (ms):
         min:                                 1373.02
         avg:                                 2987.19
         max:                                 5524.30
         95th percentile:                     4517.90

TPS dropped from 1039 to 1.32 — even worse than 1s network latency! 30% packet loss causes massive TCP retransmissions, and each Galera certification round can take several seconds. But critically: zero errors, zero reconnects, no node expulsion.

Verify data integrity after cleanup:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=2426416412, sbtest2=1176558970, sbtest3=4292186888, sbtest4=1305861152
md-1: sbtest1=2426416412, sbtest2=1176558970, sbtest3=4292186888, sbtest4=1305861152
md-2: sbtest1=2426416412, sbtest2=1176558970, sbtest3=4292186888, sbtest4=1305861152

Result: PASS — 30% packet loss caused extreme throughput degradation (TPS: 1039 → 1.32) but no node was expelled and no data was lost. Galera’s TCP-based replication handles retransmissions correctly. All checksums match.

Clean up:

➤ kubectl delete -f 1-single-experiments/packet-loss.yaml
networkchaos.chaos-mesh.org "mariadb-cluster-packet-loss" deleted

Chaos#8: Full Cluster Kill

We kill ALL 3 pods simultaneously — the worst-case scenario. This tests Galera’s ability to bootstrap from a complete outage with no surviving member.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: mariadb-full-cluster-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: all
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
  gracePeriod: 0

What this chaos does: Kills all 3 MariaDB pods simultaneously. No surviving node means the cluster must bootstrap from scratch using the data on PVCs.

Expected behavior: All 3 pods killed → cluster NotReady, no primary component → coordinator identifies pod with highest seqno (via --wsrep-recover) → bootstraps that pod with --wsrep-new-cluster → other pods rejoin via IST/SST → cluster Ready. Zero data loss.
Actual result: All 3 pods recreated. Coordinator detected full outage, ran seqno recovery, bootstrapped the highest-seqno node, other 2 rejoined. Full recovery in ~3 min. Post-recovery TPS 1024. 25/25 tracking rows and checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f full-cluster-kill.yaml
podchaos.chaos-mesh.org/mariadb-full-cluster-kill created

All pods are killed and recreated. The database immediately goes NotReady:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    NotReady   112m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          10s   Unknown
pod/md-1   2/2     Running   0          10s   Unknown
pod/md-2   2/2     Running   0          10s   Unknown

All pods show role Unknown — the Galera cluster has no quorum, no primary component. The KubeDB coordinator detects this and initiates a Galera bootstrap sequence:

The coordinator identifies the node with the most recent GTID (highest seqno)
That node is bootstrapped as the new primary component (--wsrep-new-cluster)
The other 2 nodes join the bootstrapped cluster via IST/SST

After approximately 3 minutes, all nodes rejoin and the cluster becomes Ready:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS   AGE
mariadb.kubedb.com/md   11.8.5    Ready    115m

NAME       READY   STATUS    RESTARTS   AGE     ROLE
pod/md-0   2/2     Running   0          2m59s   Primary
pod/md-1   2/2     Running   0          2m59s   Primary
pod/md-2   2/2     Running   0          2m59s   Primary

All 3 nodes back to Primary, Galera fully operational:

➤ # All nodes:
md-0: wsrep_cluster_size=3, Synced, wsrep_ready=ON
md-1: wsrep_cluster_size=3, Synced, wsrep_ready=ON
md-2: wsrep_cluster_size=3, Synced, wsrep_ready=ON

Run sysbench to confirm throughput is restored:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1014.09 qps: 20295.00 lat (ms,95%): 5.47 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1027.82 qps: 20559.23 lat (ms,95%): 5.28 err/s: 0.20 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1030.61 qps: 20616.72 lat (ms,95%): 5.18 err/s: 0.20 reconn/s: 0.00

SQL statistics:
    transactions:                        15367  (1024.26 per sec.)
    queries:                             307372 (20487.38 per sec.)
    ignored errors:                      2      (0.13 per sec.)
    reconnects:                          0      (0.00 per sec.)

Verify data integrity:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3947591857, sbtest2=3914957582, sbtest3=901119555, sbtest4=4023705335
md-1: sbtest1=3947591857, sbtest2=3914957582, sbtest3=901119555, sbtest4=4023705335
md-2: sbtest1=3947591857, sbtest2=3914957582, sbtest3=901119555, sbtest4=4023705335

Result: PASS — Full cluster kill (all 3 pods) recovered automatically via Galera bootstrap in ~3 minutes. KubeDB coordinator handled the bootstrap sequence — no manual intervention needed. 1024 TPS post-recovery. Zero data loss — all 25 tracking rows preserved, all checksums match.

Clean up:

➤ kubectl delete podchaos mariadb-full-cluster-kill -n chaos-mesh
podchaos.chaos-mesh.org "mariadb-full-cluster-kill" deleted

Chaos#9: DNS Error

We inject DNS errors on one cluster node to see if it affects Galera replication.

apiVersion: chaos-mesh.org/v1alpha1
kind: DNSChaos
metadata:
  name: mariadb-dns-error-primary
  namespace: chaos-mesh
spec:
  action: error
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  duration: "3m"

What this chaos does: Makes all DNS lookups fail on one MariaDB pod. Tests whether Galera replication (which uses IP addresses internally) is affected by DNS failures.

Expected behavior: DNS resolution blocked on one pod → Galera uses pre-resolved IPs for cluster communication, so no impact → all 3 nodes stay Synced, TPS unchanged. Zero data loss.
Actual result: All 3 nodes stayed Synced throughout 3-minute DNS chaos. 1016 TPS (97.8% of baseline — noise-level impact). 25/25 tracking rows and checksums match. PASS.

Apply and check:

➤ kubectl apply -f 1-single-experiments/dns-error-primary.yaml
dnschaos.chaos-mesh.org/mariadb-dns-error-primary created

All 3 nodes remain Synced — Galera uses IP addresses for cluster communication, not DNS:

➤ # Galera status during DNS error:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0193
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0193
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0182

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1011.69 qps: 20251.63 lat (ms,95%): 5.47 err/s: 0.20 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1022.82 qps: 20449.23 lat (ms,95%): 5.09 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1013.21 qps: 20267.98 lat (ms,95%): 5.47 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        15242  (1015.94 per sec.)
    queries:                             304857 (20319.98 per sec.)
    ignored errors:                      1      (0.07 per sec.)
    reconnects:                          0      (0.00 per sec.)

1016 TPS — virtually no impact. Verify:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=286824257, sbtest2=4261772161
md-1: sbtest1=286824257, sbtest2=4261772161
md-2: sbtest1=286824257, sbtest2=4261772161

Result: PASS — DNS errors had no impact on Galera replication. Galera communicates via IP addresses, so DNS failures don’t affect cluster operations. 1016 TPS (97.8% of baseline).

Chaos#10: IO Fault (EIO 50%)

We inject IO errors (errno 5 = EIO) on 50% of disk operations on one node. This simulates disk corruption or failing storage hardware.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: mariadb-primary-io-fault
  namespace: chaos-mesh
spec:
  action: fault
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  volumePath: "/var/lib/mysql"
  path: "/**"
  errno: 5
  percent: 50
  duration: "3m"

What this chaos does: Returns EIO (Input/output error) for 50% of all disk operations on /var/lib/mysql. This is more severe than IO latency — it causes actual data access failures.

Expected behavior: Real I/O errors → MariaDB crashes on affected node → Galera expels it → remaining 2 nodes continue serving → after chaos ends, coordinator rejoins the crashed node via IST/SST → cluster Ready. Zero data loss.
Actual result: md-0 crashed (role became Unknown). Remaining 2 nodes (md-1, md-2) stayed Primary, served traffic. After chaos cleared, coordinator rejoined md-0 and cluster returned to Ready. 25/25 tracking rows and checksums match. PASS.

Apply the chaos:

➤ kubectl apply -f 1-single-experiments/io-fault-primary.yaml
iochaos.chaos-mesh.org/mariadb-primary-io-fault created

The affected node (md-0) crashes with a segfault — MariaDB cannot handle random IO errors on its data files:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    Critical   129m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          17m   Unknown
pod/md-1   2/2     Running   0          17m   Primary
pod/md-2   2/2     Running   0          17m   Primary

➤ # md-0 (crashed):
ERROR 2002 (HY000): Can't connect to local server through socket '/run/mysqld/mysqld.sock' (111)

➤ # md-1 (healthy):
wsrep_flow_control_paused  0.0222942
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_ready                ON

➤ # md-2 (healthy):
wsrep_flow_control_paused  0.0215375
wsrep_local_state_comment  Synced
wsrep_cluster_size         2
wsrep_cluster_status       Primary
wsrep_ready                ON

MariaDB logs show: Segmentation fault (core dumped). The remaining 2 nodes continue serving traffic:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1391.02 qps: 27830.18 lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1409.46 qps: 28191.89 lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1411.61 qps: 28231.51 lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        21065  (1404.01 per sec.)
    queries:                             421300 (28080.23 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

1404 TPS on 2 nodes. After chaos expires, the KubeDB coordinator detects the crashed node, restarts it, and it rejoins via IST:

➤ # After recovery:
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=3560624458, sbtest2=1590320566
md-1: sbtest1=3560624458, sbtest2=1590320566
md-2: sbtest1=3560624458, sbtest2=1590320566

Result: PASS — IO faults caused MariaDB to segfault on the affected node, but the remaining 2 nodes continued at 1404 TPS. After chaos expired, the crashed node was recovered by the coordinator. Zero data loss.

Chaos#11: Clock Skew (-5 min)

We shift the clock backward by 5 minutes on one node. This tests whether time-dependent operations (certificates, timeouts, GTID ordering) are affected.

apiVersion: chaos-mesh.org/v1alpha1
kind: TimeChaos
metadata:
  name: mariadb-primary-clock-skew
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  timeOffset: "-5m"
  duration: "3m"

What this chaos does: Shifts the system clock backward by 5 minutes on one pod. This can confuse time-dependent operations like TLS certificate validation, timeout calculations, and log ordering.

Expected behavior: Clock skewed -5 min on one node → Galera certification uses write-set ordering (not wall clock) → minor impact at most → cluster stays Synced on all 3 nodes. Zero data loss.
Actual result: 988 TPS (5% drop), 3 ignored errors (transient deadlocks from skewed timestamps). All 3 nodes stayed Synced. 25/25 tracking rows and checksums match. PASS.

Apply and check:

➤ kubectl apply -f 1-single-experiments/clock-skew-primary.yaml
timechaos.chaos-mesh.org/mariadb-primary-clock-skew created

All 3 nodes remain Synced:

➤ # Galera status during clock skew:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0165
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0161

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 973.31 qps: 19488.47 lat (ms,95%): 6.09 err/s: 0.40 reconn/s: 0.00
[ 10s ] thds: 4 tps: 995.79 qps: 19915.27 lat (ms,95%): 5.88 err/s: 0.20 reconn/s: 0.00
[ 15s ] thds: 4 tps: 996.42 qps: 19930.23 lat (ms,95%): 5.47 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        14832  (988.48 per sec.)
    queries:                             296691 (19772.96 per sec.)
    ignored errors:                      3      (0.20 per sec.)
    reconnects:                          0      (0.00 per sec.)

988 TPS — minor 5% drop. 3 ignored errors (likely deadlocks from skewed timestamps). Verify:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=1081956110, sbtest2=4193306675
md-1: sbtest1=1081956110, sbtest2=4193306675
md-2: sbtest1=1081956110, sbtest2=4193306675

Result: PASS — 5-minute clock skew caused only a minor throughput dip (5%) and 3 ignored errors. Galera certification is based on write-set ordering, not wall-clock time, so clock skew has minimal impact.

Chaos#12: Bandwidth Throttle (1 mbps)

We throttle network bandwidth to 1 mbps on one node. This simulates a severely constrained network link.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-bandwidth-throttle
  namespace: chaos-mesh
spec:
  action: bandwidth
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  bandwidth:
    rate: "1mbps"
    limit: 20971520
    buffer: 10000
  duration: "3m"

What this chaos does: Limits the outbound bandwidth of one node to 1 mbps. This severely restricts the amount of data the node can send for Galera replication and client responses.

Expected behavior: Bandwidth throttled on one node → that node falls behind on write-set replication → Galera flow control pauses the writer side to let it catch up → TPS drops significantly but cluster stays Synced → zero errors. Zero data loss.
Actual result: TPS dropped from 1039 → 280 (-73%). wsrep_flow_control_paused increased to ~0.02 (Galera pausing writers). All 3 nodes stayed Synced, zero errors. 25/25 tracking rows and checksums match. PASS.

Apply and check:

➤ kubectl apply -f 1-single-experiments/bandwidth-throttle.yaml
networkchaos.chaos-mesh.org/mariadb-bandwidth-throttle created

All 3 nodes remain Synced, but flow control kicks in:

➤ # Galera status during bandwidth throttle:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0247
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0202
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0197

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 282.18 qps: 5651.74 (r/w/o: 3957.88/903.93/789.94) lat (ms,95%): 41.85 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 278.00 qps: 5565.80 (r/w/o: 3895.40/885.00/785.40) lat (ms,95%): 41.85 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 281.40 qps: 5627.60 (r/w/o: 3939.20/898.00/790.40) lat (ms,95%): 41.85 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        4212   (280.27 per sec.)
    queries:                             84240  (5605.35 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Latency (ms):
         min:                                    2.80
         avg:                                   14.25
         max:                                   50.38
         95th percentile:                       41.85

TPS dropped from 1039 to 280 (73% reduction). The 1 mbps bandwidth limit constrains how fast write-sets can be replicated. P95 latency increased from 5ms to 42ms. But zero errors — the cluster self-throttles via Galera flow control.

Note the wsrep_flow_control_paused values are slightly elevated (0.02) — Galera is pausing writers to prevent the slow node from falling too far behind.

Verify data integrity after cleanup:

➤ # Tracking rows — all match
md-0 markers: 25
md-1 markers: 25
md-2 markers: 25

➤ # Checksums — all match
md-0: sbtest1=410521570, sbtest2=126349543, sbtest3=2842752298, sbtest4=2843785900
md-1: sbtest1=410521570, sbtest2=126349543, sbtest3=2842752298, sbtest4=2843785900
md-2: sbtest1=410521570, sbtest2=126349543, sbtest3=2842752298, sbtest4=2843785900

Result: PASS — Bandwidth throttle caused significant throughput degradation (73%) but Galera flow control kept all nodes Synced with zero errors. No data loss.

Chaos#13: Pod Failure (5 min pause)

Unlike pod-kill which deletes and recreates the pod, pod-failure pauses the pod — making it completely unresponsive while the container appears to be Running.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: mariadb-primary-pod-failure
  namespace: chaos-mesh
spec:
  action: pod-failure
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  duration: "5m"

What this chaos does: Freezes one pod completely — the container appears Running but is unresponsive. This simulates a hung process or kernel-level freeze.

Expected behavior: One pod frozen (appears Running but unresponsive) → Galera heartbeats fail → expelled from cluster → remaining 2 nodes serve traffic → after chaos, frozen pod resumes and rejoins via IST. Zero data loss.
Actual result: md-1 frozen, shown as Unknown role; remaining md-0/md-2 kept Primary with wsrep_cluster_size=2, served 1409 TPS with zero errors. After chaos expired, md-1 resumed and rejoined. 25/25 tracking rows and checksums match. PASS.

During chaos, the frozen pod (md-1) shows container not found when exec’d:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    Critical   149m

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          37m   Primary
pod/md-1   2/2     Running   0          37m   Unknown
pod/md-2   2/2     Running   0          37m   Primary

➤ # md-0: wsrep_cluster_size=2, Synced, wsrep_ready=ON
➤ # md-1: error: container not found ("mariadb")
➤ # md-2: wsrep_cluster_size=2, Synced, wsrep_ready=ON

The remaining 2 nodes continue serving traffic:

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1415.21 qps: 28314.94 lat (ms,95%): 3.49 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1420.69 qps: 28413.41 lat (ms,95%): 3.43 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1390.60 qps: 27812.97 lat (ms,95%): 3.68 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        21137  (1408.83 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Result: PASS — Pod freeze handled gracefully. 1409 TPS on 2 nodes, 0 errors. After chaos expired, frozen pod restarted and rejoined. 25/25 markers, checksums match.

Chaos#14: Container Kill (mariadb process only)

We kill only the mariadb container, not the entire pod. This tests whether the pod-level restart (by kubelet) and the coordinator can recover the database process.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: mariadb-kill-mariadb-process
  namespace: chaos-mesh
spec:
  action: container-kill
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  containerNames:
    - mariadb
  duration: "30s"

What this chaos does: Kills only the mariadb container inside the pod. The coordinator container keeps running. Kubelet restarts the killed container automatically.

Expected behavior: mariadb container killed → kubelet restarts it → coordinator detects restart and rejoins the node to Galera → remaining 2 nodes serve during the restart window → all 3 back Synced. Zero data loss.
Actual result: md-1 mariadb container killed (restart count 5). Remaining md-0/md-2 kept Primary with wsrep_cluster_size=2, served 1381 TPS. Coordinator rejoined md-1 after restart. 25/25 tracking rows and checksums match. PASS.

➤ kubectl get pods -n demo -L kubedb.com/role
NAME   READY   STATUS    RESTARTS      AGE   ROLE
md-0   2/2     Running   0             16h   Primary
md-1   2/2     Running   5 (15s ago)   16h   Unknown
md-2   2/2     Running   0             16h   Primary

➤ # md-0: wsrep_cluster_size=2, Synced, wsrep_flow_control_paused=0.0001
➤ # md-1: ERROR 2002 - Can't connect to local server through socket
➤ # md-2: wsrep_cluster_size=2, Synced, wsrep_flow_control_paused=0.0004

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1403.41 qps: 28080.43 lat (ms,95%): 3.55 err/s: 0.20 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1368.89 qps: 27381.54 lat (ms,95%): 3.82 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1370.59 qps: 27412.22 lat (ms,95%): 3.68 err/s: 0.20 reconn/s: 0.00

SQL statistics:
    transactions:                        20719  (1380.96 per sec.)
    ignored errors:                      2      (0.13 per sec.)
    reconnects:                          0      (0.00 per sec.)

Result: PASS — Container kill handled by kubelet restart. 1381 TPS on 2 nodes. Coordinator detected the restart and rejoined the node. 25/25 markers, checksums match.

Chaos#15: Packet Duplicate (50%)

We inject 50% packet duplication. Unlike packet loss, duplicated packets arrive multiple times, which can confuse protocols that aren’t idempotent.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-primary-packet-duplicate
  namespace: chaos-mesh
spec:
  action: duplicate
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  target:
    mode: all
    selector:
      namespaces:
        - demo
      labelSelectors:
        "app.kubernetes.io/instance": "md"
  duplicate:
    duplicate: "50"
    correlation: "25"
  duration: "10m"
  direction: both

Expected behavior: 50% packet duplication → TCP dedups duplicates via sequence numbers → Galera certification unaffected → cluster stays Synced on all 3 nodes → minimal TPS impact. Zero data loss.
Actual result: 995 TPS (4% drop). All 3 nodes stayed Synced throughout. Zero errors, 25/25 tracking rows and checksums match. PASS — TCP handles duplicate packets natively.

All 3 nodes remain Synced:

➤ # Galera status during 50% packet duplication:
md-0: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0001
md-1: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0
md-2: wsrep_cluster_size=3, Synced, wsrep_flow_control_paused=0.0004

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 988.07 qps: 19773.62 lat (ms,95%): 5.67 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1009.84 qps: 20196.64 lat (ms,95%): 5.57 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 986.39 qps: 19727.30 lat (ms,95%): 5.57 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        14926  (994.79 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Result: PASS — 50% packet duplication caused only a minor 4% TPS drop (995 vs 1039). TCP handles duplicate packets natively (sequence numbers), so Galera is unaffected. Zero errors, all nodes Synced. 25/25 markers, checksums match.

Chaos#16: Packet Corrupt (50%)

We corrupt 50% of all packets. This is the most severe network chaos — corrupt packets fail TCP checksums, causing retransmissions that compound with Galera’s certification protocol.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mariadb-primary-packet-corrupt
  namespace: chaos-mesh
spec:
  action: corrupt
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  target:
    mode: all
    selector:
      namespaces:
        - demo
      labelSelectors:
        "app.kubernetes.io/instance": "md"
  corrupt:
    corrupt: "50"
    correlation: "25"
  duration: "10m"
  direction: both

Expected behavior: 50% packet corruption → corrupt packets fail TCP checksum → massive retransmissions → Galera group communication breaks → all nodes may lose quorum (worst case). After chaos lifts, coordinator must bootstrap cluster. Zero data loss.
Actual result: All 3 nodes lost quorum (wsrep_cluster_size=1, non-Primary, wsrep_ready=OFF). Sysbench got error 1047 (WSREP not ready). After chaos removed, coordinator detected full outage and automatically bootstrapped the cluster. 25/25 tracking rows and checksums match after recovery. PASS — worst-case Galera failure, but data survived.

This is the most severe chaos experiment. 50% packet corruption completely broke the Galera cluster:

➤ # ALL 3 nodes lost quorum:
md-0: wsrep_cluster_size=1, non-Primary, wsrep_ready=OFF, Initialized
md-1: wsrep_cluster_size=1, non-Primary, wsrep_ready=OFF, Initialized
md-2: wsrep_cluster_size=1, non-Primary, wsrep_ready=OFF, Initialized

➤ sysbench:
FATAL: mysql_stmt_execute() returned error 1047 (WSREP has not yet prepared node for application use)

The cluster was completely non-functional — all nodes became standalone (cluster_size=1) with non-Primary status. No node could accept writes (error 1047). This happened because corrupt packets broke the group communication protocol — nodes couldn’t exchange valid heartbeats or certification messages.

After removing the chaos, the KubeDB coordinator detected the complete outage and bootstrapped the cluster:

➤ kubectl get mariadb -n demo md
NAME   VERSION   STATUS   AGE
md     11.8.5    Ready    18h

Result: PASS — 50% packet corruption caused a complete cluster outage (all nodes non-Primary). This is the expected worst case — Galera cannot function when half of all packets are corrupted. However, after chaos removal, the coordinator automatically bootstrapped the cluster with zero data loss. 25/25 markers, checksums match.

Chaos#17: IO Attr Override (read-only filesystem)

We override file attributes to make the data directory read-only. This simulates a read-only filesystem mount or permissions issue.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: mariadb-primary-io-attr-override
  namespace: chaos-mesh
spec:
  action: attrOverride
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  volumePath: /var/lib/mysql
  path: /var/lib/mysql/**/*
  attr:
    perm: 444
  percent: 100
  duration: "10m"
  containerNames:
    - mariadb

What this chaos does: Makes all files in /var/lib/mysql read-only (perm 444). MariaDB cannot write WAL, flush pages, or commit transactions.

Expected behavior: Data dir becomes read-only on one node → MariaDB fails on writes and crashes → Galera expels the node → remaining 2 nodes continue serving → after chaos ends, coordinator recovers the crashed node (likely via SST). Zero data loss.
Actual result: md-2 crashed (role Unknown, socket unavailable). md-0/md-1 kept Primary with wsrep_cluster_size=2, served 1388 TPS with zero errors. Coordinator recovered md-2 after chaos cleared. 25/25 tracking rows and checksums match. PASS.

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    Critical   18h

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          16h   Primary
pod/md-1   2/2     Running   5          16h   Primary
pod/md-2   2/2     Running   0          16h   Unknown

➤ # md-0: wsrep_cluster_size=2, Synced, wsrep_ready=ON
➤ # md-2 (affected): ERROR 2002 - Can't connect to local server
➤ # md-1: wsrep_cluster_size=2, Synced, wsrep_ready=ON

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1384.82 qps: 27707.45 lat (ms,95%): 3.62 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1381.28 qps: 27625.71 lat (ms,95%): 3.55 err/s: 0.20 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1397.80 qps: 27962.05 lat (ms,95%): 3.49 err/s: 0.20 reconn/s: 0.00

SQL statistics:
    transactions:                        20824  (1387.98 per sec.)
    ignored errors:                      2      (0.13 per sec.)
    reconnects:                          0      (0.00 per sec.)

Result: PASS — Read-only filesystem crashed MariaDB on the affected node. Remaining 2 nodes served 1388 TPS. After chaos expired, coordinator recovered the node. 25/25 markers, checksums match.

Chaos#18: IO Mistake (random data corruption in IO)

We inject random bytes into 50% of disk read/write operations. This is the most dangerous IO chaos — it corrupts actual data being read from or written to disk.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: mariadb-primary-io-mistake
  namespace: chaos-mesh
spec:
  action: mistake
  mode: one
  selector:
    namespaces:
      - demo
    labelSelectors:
      "app.kubernetes.io/instance": "md"
      "kubedb.com/role": "Primary"
  volumePath: /var/lib/mysql
  path: /var/lib/mysql/**/*
  mistake:
    filling: random
    maxOccurrences: 10
    maxLength: 100
  percent: 50
  duration: "10m"
  containerNames:
    - mariadb

What this chaos does: Replaces up to 10 occurrences of up to 100 bytes with random data in 50% of IO operations. This corrupts InnoDB pages, WAL entries, and metadata.

Expected behavior: Random data corruption on disk → InnoDB page checksums detect corruption → MariaDB crashes on the affected node → Galera expels it → remaining 2 nodes continue → coordinator recovers the corrupted node via full SST (data cannot be salvaged). Zero data loss on surviving nodes.
Actual result: md-1 crashed (page corruption detected by InnoDB checksums). md-0/md-2 kept Primary with wsrep_cluster_size=2, served 1380 TPS with zero errors. Coordinator recovered md-1 via SST from a healthy node. 25/25 tracking rows and checksums match across all 3 nodes. PASS.

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                    VERSION   STATUS     AGE
mariadb.kubedb.com/md   11.8.5    Critical   18h

NAME       READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0   2/2     Running   0          16h   Primary
pod/md-1   2/2     Running   5          16h   Unknown
pod/md-2   2/2     Running   0          16h   Primary

➤ # md-0: wsrep_cluster_size=2, Synced, wsrep_ready=ON
➤ # md-1 (affected): ERROR 2002 - Can't connect
➤ # md-2: wsrep_cluster_size=2, Synced, wsrep_ready=ON

➤ sysbench oltp_read_write ... --time=15 --report-interval=5 run
[ 5s ] thds: 4 tps: 1352.04 qps: 27051.31 lat (ms,95%): 3.96 err/s: 0.00 reconn/s: 0.00
[ 10s ] thds: 4 tps: 1396.45 qps: 27929.02 lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00
[ 15s ] thds: 4 tps: 1390.02 qps: 27800.64 lat (ms,95%): 3.55 err/s: 0.00 reconn/s: 0.00

SQL statistics:
    transactions:                        20697  (1379.51 per sec.)
    ignored errors:                      0      (0.00 per sec.)
    reconnects:                          0      (0.00 per sec.)

Result: PASS — Random IO corruption crashed MariaDB on the affected node (data page checksums detected the corruption). Remaining 2 nodes served 1380 TPS with zero errors. The corrupted node was recovered by the coordinator (likely via SST — full state transfer from a healthy node). 25/25 markers, checksums match across all 3 nodes.

MariaDB Replication with MaxScale (28 Experiments)

Now we test 28 chaos experiments on MariaDB Replication topology with MaxScale proxy — an extended pass that goes beyond the 18 Galera experiments above with Slave-side variants (pod kill slave, memory / IO stress on slave), MaxScale-targeted chaos, compound faults, and a rolling restart. Unlike Galera (synchronous multi-master), Replication uses asynchronous Master-Slave replication with MaxScale handling automatic failover and read-write splitting.

Replication Test Environment

Component	Details
Cluster Topology	MariaDB Replication (1 Master + 2 Slaves)
Proxy	MaxScale (3 replicas)
MariaDB Version	11.8.5
Load via	`md-mx` service (MaxScale, port 3306)
Baseline TPS	~926 (via MaxScale)

Deploy MariaDB Replication with MaxScale

apiVersion: kubedb.com/v1
kind: MariaDB
metadata:
  name: md
  namespace: demo
spec:
  deletionPolicy: Delete
  replicas: 3
  storage:
    accessModes:
      - ReadWriteOnce
    resources:
      requests:
        storage: 2Gi
  storageType: Durable
  podTemplate:
    spec:
      containers:
        - name: mariadb
          resources:
            limits:
              memory: 1.5Gi
            requests:
              cpu: 500m
              memory: 1.5Gi
  topology:
    mode: MariaDBReplication
    maxscale:
      replicas: 3
      enableUI: true
      storage:
        accessModes:
          - ReadWriteOnce
        resources:
          requests:
            storage: 100Mi
      storageType: Durable
  version: 11.8.5

Key differences from Galera:
kubedb.com/role: Master (1 node) and kubedb.com/role: Slave (2 nodes) — not multi-master
MaxScale automatically routes writes to Master, reads to Slaves
Async replication — Master doesn’t wait for Slave acknowledgment
All sysbench load goes through md-mx (MaxScale service)

Verify:

➤ kubectl get mariadb,pods -n demo -L kubedb.com/role
NAME                       VERSION   STATUS   AGE
mariadb.kubedb.com/md      11.8.5    Ready    3m

NAME         READY   STATUS    RESTARTS   AGE   ROLE
pod/md-0     2/2     Running   0          3m    Master
pod/md-1     2/2     Running   0          3m    Slave
pod/md-2     2/2     Running   0          3m    Slave
pod/md-mx-0  1/1     Running   0          3m
pod/md-mx-1  1/1     Running   0          3m
pod/md-mx-2  1/1     Running   0          3m

➤ # Replication status:
Slave_IO_Running: Yes
Slave_SQL_Running: Yes
Seconds_Behind_Master: 0

➤ # Baseline via MaxScale:
transactions: 13902 (926.35 per sec.)
reconnects: 0 (0.00 per sec.)

Standard Replication Chaos Experiments

A total of 28 chaos experiments were run on the Replication topology — deeper than Galera’s 18-test pass. We added Slave-side variants (pod kill slave, memory / IO stress on slave), MaxScale-targeted chaos, compound faults (master + MaxScale together), and a rolling restart.

All 28 experiments passed with zero data loss.

The verification methodology for each test follows the same pattern as Galera: sysbench load through MaxScale, tracking markers cross-node, and checksums matching across all nodes.

Chaos#1: Pod Kill — Master

Force-delete the Master pod to verify MaxScale-driven failover.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-master-pod-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  gracePeriod: 0

Expected behavior: Master pod deleted → MaxScale detects loss → one Slave promoted to Master → killed pod recreated and rejoins as Slave → cluster returns to Ready with zero data loss.
Actual result (PASS): Failover md-2 → md-0 in ~5s. Sysbench continued at 1043 TPS, 0 reconnects. All 3 nodes show identical CHECKSUM TABLE values post-chaos. MariaDB CR stayed Ready throughout — MaxScale kept serving.

Chaos#2: Pod Kill — Slave

Kill one Slave pod; verify it’s recreated and rejoins replication automatically.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-slave-pod-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Slave
  gracePeriod: 0

Expected behavior: Slave killed → pod recreated → CHANGE MASTER TO completes → Slave_IO_Running=Yes, Slave_SQL_Running=Yes. Writes on master continue via MaxScale.
Actual result (PASS): Sysbench maintained 1125 TPS throughout — zero write impact. Slave back to Slave_IO_Running=Yes in ~30s. Checksums match across 3 nodes.

Chaos#3: Pod Kill — MaxScale

Kill one MaxScale proxy pod; remaining MaxScale pods should keep serving.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-maxscale-pod-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md-mx
  gracePeriod: 0

Expected behavior: One MaxScale pod dies → kubernetes Service re-routes client traffic to the surviving 2 MaxScale pods → at most a transient blip.
Actual result (PASS): md-mx-0 restarted. Sysbench continued at 898 TPS via the remaining 2 MaxScale pods. No client reconnects.

Chaos#4: Container Kill — `mariadb` on Master

Kill the mariadb container (not the whole pod) on Master to simulate a process crash.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-container-kill-mariadb
  namespace: chaos-mesh
spec:
  action: container-kill
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  containerNames: [mariadb]
  duration: "30s"

Expected behavior: mariadb container SIGKILLed → kubelet restarts the container → MaxScale briefly re-routes to a Slave promoted as new Master → original pod rejoins as Slave.
Actual result (PASS): Failover md-0 → md-1 completed. Sysbench dropped briefly then recovered. Steady state in ~30s, checksums match.

Chaos#5: Pod Failure (90s freeze) — Master

Freeze the Master pod for 90 seconds to simulate kernel hang or long GC pause.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-master-pod-failure
  namespace: chaos-mesh
spec:
  action: pod-failure
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  duration: "90s"

Expected behavior: Master unresponsive → MaxScale detects failure and promotes a Slave → frozen pod killed by kubelet mid-freeze → recreated, rejoins as Slave.
Actual result (PASS): Kubelet killed the container 4× during the freeze (restart count reached 4 on md-1). Failover completed, sysbench ranged 750–1127 TPS during chaos, checksums match post-chaos.

Chaos#6: Memory Stress (1400MB) — Master

Drive 1400MB of memory pressure against Master (1.5Gi limit) to trigger OOMKill.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: md-master-memory-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  stressors:
    memory:
      workers: 2
      size: "1400MB"
  duration: "3m"

Expected behavior: OOMKiller fires → mariadb killed → MaxScale fails over to a Slave → killed pod recreated, rejoins as Slave.
Actual result (PASS): Failover md-0 → md-1 triggered by OOMKill. Sysbench 775–950 TPS. Rejoined cluster after stress cleared; checksums match.

Chaos#7: Memory Stress (1400MB) — Slave

Same stressor against a Slave — verify write path stays healthy.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: md-slave-memory-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Slave
  stressors:
    memory:
      workers: 2
      size: "1400MB"
  duration: "2m"

Expected behavior: Slave OOMKilled → pod recreated → rejoins replication. No write impact (writes only go to master).
Actual result (PASS): 1138 TPS maintained throughout — slave OOM completely invisible to writers via MaxScale. Slave caught up after restart; checksums match.

Chaos#8: CPU Stress (98%) — Master

Peg Master CPU at 98%; verify it stays stable without failover.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: md-master-cpu-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  stressors:
    cpu:
      workers: 2
      load: 98
  duration: "90s"

Expected behavior: Master CPU saturated → TPS degrades but no restart, no failover.
Actual result (PASS): Sysbench 867–950 TPS during chaos (vs 926 baseline — <10% drop). No failover. Post-chaos checksums match.

Chaos#9: Combined Memory + CPU Stress — Master

Simultaneous 1200MB memory + 90% CPU stress on Master.

apiVersion: chaos-mesh.org/v1alpha1
kind: StressChaos
metadata:
  name: md-master-combined-stress
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  stressors:
    memory:
      workers: 2
      size: "1200MB"
    cpu:
      workers: 2
      load: 90
  duration: "2m"

Expected behavior: Degraded but stable; no OOMKill (below the 1400MB threshold from Chaos#6), no failover.
Actual result (PASS): 749–958 TPS, no restart, no failover. Checksums match post-chaos.

Chaos#10: IO Latency (100ms) — Master

Inject 100ms disk latency on Master’s datadir; expect TPS to collapse (single-master write bottleneck).

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: md-master-io-latency
  namespace: chaos-mesh
spec:
  action: latency
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  volumePath: /var/lib/mysql
  path: "/**"
  delay: "100ms"
  percent: 100
  duration: "2m"
  containerNames: [mariadb]

Expected behavior: Master disk-bound → TPS drops severely → no failover (disk still functional, just slow) → recovery when chaos expires.
Actual result (PASS): TPS dropped to 5 (vs 926 baseline — extreme single-master bottleneck), 0 errors, no failover. Recovered within seconds of chaos clearing.

Chaos#11: IO Latency (100ms) — Slave

Same latency but on Slave; expect write path unaffected.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: md-slave-io-latency
  namespace: chaos-mesh
spec:
  action: latency
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Slave
  volumePath: /var/lib/mysql
  path: "/**"
  delay: "100ms"
  percent: 100
  duration: "2m"
  containerNames: [mariadb]

Expected behavior: Slave falls behind but writes continue via MaxScale → master unaffected → slave catches up after chaos.
Actual result (PASS): 1131 TPS maintained. Slave’s Seconds_Behind_Master grew during chaos and caught up after chaos cleared.

Chaos#12: IOChaos `fault` (EIO 50%) — Master

Return EIO on 50% of file operations against Master’s datadir for 2 minutes.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: md-master-io-fault
  namespace: chaos-mesh
spec:
  action: fault
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  volumePath: /var/lib/mysql
  path: "/**"
  errno: 5
  percent: 50
  duration: "2m"
  containerNames: [mariadb]

Expected behavior: Master crashes on first EIO → MaxScale fails over to a Slave → killed container restarted by kubelet → old master rejoins as Slave.
Actual result (PASS): Within seconds of chaos start, the Master’s mariadbd died (binlog writes returned Errcode: 5 "Input/output error" and InnoDB threw error 168 to clients). MaxScale flipped server2 (md-1) to Master, Running immediately and routed new traffic there. Sysbench dipped briefly (90–358 TPS range during chaos, vs ~300 TPS baseline) with no errors after the failover settled. ~30 seconds after the 2-minute chaos window cleared, md-0’s init script restarted mariadbd, the coordinator ran join_to_master against the new Master (md-1), and md-0 rejoined as a Slave. MariaDB CR returned to Ready automatically, and CHECKSUM TABLE on sbtest1, sbtest5, sbtest10 (1,000,000 rows each) matched across all three nodes — zero data loss.

Chaos#13: IOChaos `fault` (EIO 50%) — Slave

Same EIO fault injection targeting a Slave to verify behavior on the read replica path.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: md-slave-io-fault
  namespace: chaos-mesh
spec:
  action: fault
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Slave
  volumePath: /var/lib/mysql
  path: "/**"
  errno: 5
  percent: 50
  duration: "2m"
  containerNames: [mariadb]

Expected behavior: Slave’s mariadbd crashes, pod recreated, rejoins. Zero write impact on master.
Actual result (PASS): md-2’s mariadbd died within seconds of chaos start and MaxScale marked server3 Down. The Master (md-1) and other Slave (md-0) kept serving traffic — sysbench ranged 66–325 TPS through the 2-minute chaos window vs ~325 TPS baseline, with zero errors. After chaos cleared, md-2’s init script restarted mariadbd, MaxScale flipped server3 back to Slave, Running, and md-2 caught up with the master automatically. MariaDB CR returned to Ready, and CHECKSUM TABLE on sbtest1, sbtest5, sbtest10 (1,000,000 rows each) matched across all three nodes — zero data loss.

Chaos#14: IO AttrOverride (read-only datadir) — Master

Force read-only (0444) file permissions on datadir for 3 minutes.

apiVersion: chaos-mesh.org/v1alpha1
kind: IOChaos
metadata:
  name: md-master-io-attr-override
  namespace: chaos-mesh
spec:
  action: attrOverride
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  volumePath: /var/lib/mysql
  path: /var/lib/mysql/**/*
  attr:
    perm: 444
  percent: 100
  duration: "3m"
  containerNames: [mariadb]

Expected behavior: Writes fail with EACCES → mariadbd either crashes or goes degraded → recovery after chaos clears and permissions are restored.
Actual result (PASS): TPS dropped to 656, 0 errors visible to clients, no crash. Permissions restored post-chaos, full recovery. Checksums match across 3 nodes.

Chaos#15: Network Partition — Master ↔ Slaves

Cut network between Master and the two Slaves for 90 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-master-slaves-partition
  namespace: chaos-mesh
spec:
  action: partition
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
        kubedb.com/role: Slave
  direction: both
  duration: "90s"

Expected behavior: Async replication lag grows on both slaves → no failover (master keeps accepting writes) → replication catches up after partition clears.
Actual result (PASS): 1122 TPS maintained — master writes unaffected (async replication). Slaves’ Seconds_Behind_Master grew during partition, dropped to 0 after chaos cleared. Checksums match post-chaos.

Chaos#16: Network Partition — Slave isolated

Isolate one Slave from the rest of the cluster for 90 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-slave-isolated
  namespace: chaos-mesh
spec:
  action: partition
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Slave
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
  direction: both
  duration: "90s"

Expected behavior: Isolated slave falls behind, MaxScale stops routing reads to it → master + other slave continue serving → slave catches up after chaos.
Actual result (PASS): 964 TPS — no write impact. Isolated slave lag grew, then caught up after partition cleared.

Chaos#17: Network Partition — MaxScale ↔ MariaDB

Cut network between all MaxScale pods and all MariaDB pods for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: mx-md-partition
  namespace: chaos-mesh
spec:
  action: partition
  mode: all
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md-mx
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
  direction: both
  duration: "60s"

Expected behavior: Clients lose connection (MaxScale can’t reach backends) → no writes during partition → MaxScale reconnects when partition clears → full recovery.
Actual result (PASS): TPS dropped to 0 during chaos (sysbench lost connections as expected). After partition cleared, sysbench reconnected and recovered to 955 TPS. Checksums match.

Chaos#18: Network Latency (1s) — Master ↔ Slaves

Add 1 second of latency between Master and Slaves for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-net-latency-1s
  namespace: chaos-mesh
spec:
  action: delay
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
        kubedb.com/role: Slave
  delay:
    latency: "1s"
    jitter: "50ms"
  duration: "60s"
  direction: both

Expected behavior: Slaves lag by ~1s, master unaffected (async replication doesn’t wait for slave ack).
Actual result (PASS): 1148 TPS — zero impact. Key contrast: the same test on Galera tanks TPS to ~3 TPS because synchronous certification requires slave acknowledgment.

Chaos#19: Packet Loss (30%)

Drop 30% of packets between Master and Slaves for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-packet-loss
  namespace: chaos-mesh
spec:
  action: loss
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
  loss:
    loss: "30"
    correlation: "25"
  duration: "60s"
  direction: both

Expected behavior: Master-slave replication slows due to TCP retransmits; master unaffected.
Actual result (PASS): 954 TPS — no write impact. Slave lag grew, recovered after chaos.

Chaos#20: Packet Duplicate (50%)

Duplicate 50% of packets between master and slaves.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-packet-duplicate
  namespace: chaos-mesh
spec:
  action: duplicate
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
  duplicate:
    duplicate: "50"
    correlation: "25"
  duration: "45s"
  direction: both

Expected behavior: TCP handles duplicate packets transparently → no impact.
Actual result (PASS): 948 TPS, no impact as expected.

Chaos#21: Packet Corrupt (50%)

Corrupt 50% of packets (bit-flip) between master and slaves.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-packet-corrupt
  namespace: chaos-mesh
spec:
  action: corrupt
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  target:
    mode: all
    selector:
      namespaces: [demo]
      labelSelectors:
        app.kubernetes.io/instance: md
  corrupt:
    corrupt: "50"
    correlation: "25"
  duration: "45s"
  direction: both

Expected behavior: TCP checksums drop corrupt packets → retransmitted → replication slightly slower, master unaffected.
Actual result (PASS): 1156 TPS — no impact. Stark contrast with Galera, where the same test causes complete outage because wsrep requires valid certification packets.

Chaos#22: Bandwidth 1 Mbps — Master

Throttle Master’s network to 1 Mbps for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: NetworkChaos
metadata:
  name: md-bandwidth-1mbps
  namespace: chaos-mesh
spec:
  action: bandwidth
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  bandwidth:
    rate: "1mbps"
    limit: 20971520
    buffer: 10000
  duration: "60s"

Expected behavior: Severely throttled TPS, 0 errors, instant recovery after chaos.
Actual result (PASS): TPS dropped to 21 (-97%) — all clients connected, 0 errors. Recovered instantly after chaos cleared.

Chaos#23: DNS Error — Master

Inject DNS resolution errors on Master for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: DNSChaos
metadata:
  name: md-dns-error
  namespace: chaos-mesh
spec:
  action: error
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  duration: "60s"

Expected behavior: No impact — MariaDB uses cached/resolved IPs for peer connections.
Actual result (PASS): 956 TPS — completely unaffected.

Chaos#24: Clock Skew (-5 min) — Master

Set Master’s clock back 5 minutes for 60 seconds.

apiVersion: chaos-mesh.org/v1alpha1
kind: TimeChaos
metadata:
  name: md-clock-skew
  namespace: chaos-mesh
spec:
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  timeOffset: "-5m"
  duration: "60s"

Expected behavior: Timestamps mildly affected, replication continues.
Actual result (PASS): 879 TPS (minor dip from 926). No replication errors.

Chaos#25: Full MariaDB Cluster Kill

Kill all 3 MariaDB pods simultaneously to test full-outage recovery.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-full-cluster-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: all
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
  gracePeriod: 0

Expected behavior: All 3 pods killed and recreated → KubeDB coordinator identifies the most up-to-date node and bootstraps the cluster → replication re-established.
Actual result (PASS): Recovery ~75s. Coordinator bootstrapped the correct node, re-established master/slaves. 12/12 tracking markers preserved.

Chaos#26: Full MaxScale Kill

Kill all 3 MaxScale pods simultaneously.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-mx-full-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: all
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md-mx
  gracePeriod: 0

Expected behavior: All MaxScale pods killed, clients lose access, recover when MaxScale pods come back. MariaDB cluster itself unaffected.
Actual result (PASS): ~3-minute client outage (MaxScale pods restarted sequentially). After recovery, sysbench resumed at 955 TPS. Master/slaves unaffected during the outage; checksums match.

Chaos#27: Compound — Master + all MaxScale kill

Simultaneously kill Master and all 3 MaxScale pods.

apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-master-compound-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: one
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md
      kubedb.com/role: Master
  gracePeriod: 0
---
apiVersion: chaos-mesh.org/v1alpha1
kind: PodChaos
metadata:
  name: md-mx-compound-kill
  namespace: chaos-mesh
spec:
  action: pod-kill
  mode: all
  selector:
    namespaces: [demo]
    labelSelectors:
      app.kubernetes.io/instance: md-mx
  gracePeriod: 0

Expected behavior: Both Master and MaxScale path broken → full outage → MaxScale restarts, Slave promoted to Master, recovery.
Actual result (PASS): Recovery ~90s. md-0 re-elected Master. 14/14 tracking markers preserved.

Chaos#28: Rolling Restart (0 → 1 → 2, rapid)

Delete md-0, md-1, md-2 sequentially with ~40s gaps (faster than KubeDB’s internal convergence).

kubectl delete pod md-0 -n demo --grace-period=0 --force
sleep 40
kubectl delete pod md-1 -n demo --grace-period=0 --force
sleep 40
kubectl delete pod md-2 -n demo --grace-period=0 --force

Expected behavior: Each pod restarts and rejoins the cluster. May briefly show roles Down during rapid succession; eventually converges.
Actual result (PASS): All 3 roles briefly showed Down during the rapid sequence (kubelet didn’t have time to settle between deletes). Cluster recovered to Master + 2× Slave in ~2m30s. 15/15 tracking markers preserved. Coordinator handled the unusual sequence correctly.

Chaos Testing Results Summary

We ran 46 chaos experiments across 2 MariaDB topologies — 18 on Galera (all PASS) and 28 on Replication + MaxScale (all PASS). All 46 experiments completed with zero data loss.

Galera Cluster Results (18 experiments, baseline ~1039 TPS)

#	Experiment	TPS During	Impact	Recovery	Data
1	Pod Kill	1061	None	~5s auto-rejoin	25/25
2	OOMKill (1200MB)	1050	None (survived)	N/A	25/25
3	Network Partition	1430 (+37%)	TPS increased (2 nodes)	Auto-rejoin	25/25
4	IO Latency (100ms)	1450 (2 nodes)	Node unresponsive	Auto-rejoin	25/25
5	Network Latency (1s)	3 (-99.7%)	Severe	Instant	25/25
6	CPU Stress (98%)	1034	Negligible	N/A	25/25
7	Packet Loss (30%)	1.3 (-99.9%)	Severe	Instant	25/25
8	Full Cluster Kill	1024	Full outage	~3 min bootstrap	25/25
9	DNS Error	1016	None	N/A	25/25
10	IO Fault (EIO 50%)	1404 (2 nodes)	Node crash	Coordinator	25/25
11	Clock Skew (-5 min)	988 (-5%)	Minor	Instant	25/25
12	Bandwidth Throttle	280 (-73%)	Significant	Instant	25/25
13	Pod Failure (freeze)	1409 (2 nodes)	Node frozen	Auto-rejoin	25/25
14	Container Kill	1381 (2 nodes)	Process killed	Kubelet restart	25/25
15	Packet Duplicate (50%)	995 (-4%)	Minor	N/A	25/25
16	Packet Corrupt (50%)	0 (all down)	Complete outage	Auto-bootstrap	25/25
17	IO Attr Override (r/o)	1388 (2 nodes)	Node crash	Coordinator	25/25
18	IO Mistake (corruption)	1380 (2 nodes)	Node crash	SST recovery	25/25

Replication + MaxScale Results (28 experiments, baseline ~926 TPS)

#	Experiment	Result	TPS During	Notes
1	Pod Kill — Master	PASS	1043	Failover md-2 → md-0, rejoin as Slave
2	Pod Kill — Slave	PASS	1125	Zero write impact
3	Pod Kill — MaxScale	PASS	898	Routing kept via remaining MaxScale pods
4	Container Kill — mariadb on Master	PASS	—	Failover, ~30s to steady state
5	Pod Failure (90s freeze) on Master	PASS	750–1127	Kubelet killed container 4× during freeze
6	Memory stress (1400MB) on Master	PASS	775–950	OOMKilled, failover, rejoined
7	Memory stress (1400MB) on Slave	PASS	1138	Writes via MaxScale → master unaffected
8	CPU stress 98% on Master	PASS	867–950	No failover, stable
9	Combined Memory + CPU on Master	PASS	749–958	Survived
10	IO Latency (100ms) on Master	PASS	5	Severe throttle, 0 errors
11	IO Latency (100ms) on Slave	PASS	1131	Writes unaffected
12	IOChaos `fault` (EIO 50%) on Master	PASS	90–358	MaxScale promoted Slave instantly; ex-Master auto-rejoined ~30s after chaos cleared
13	IOChaos `fault` (EIO 50%) on Slave	PASS	66–325	Slave’s mariadbd died; Master + other Slave kept serving; auto-rejoin after chaos cleared
14	IO AttrOverride (read-only) on Master	PASS	656	Degraded, no crash, auto-recovered
15	Network Partition (Master ↔ Slaves, 90s)	PASS	1122	No failover (async replication)
16	Network Partition (Slave isolated, 90s)	PASS	964	No write impact
17	Network Partition (MaxScale ↔ MariaDB, 60s)	PASS	0 / 955	Lost conn during, full recovery after
18	Network Latency 1s	PASS	1148	Zero impact (async)
19	Packet Loss 30%	PASS	954	No write impact
20	Packet Duplicate 50%	PASS	948	No impact
21	Packet Corrupt 50%	PASS	1156	No impact
22	Bandwidth 1 Mbps on Master	PASS	21	-97% TPS, 0 errors
23	DNS Error on Master	PASS	956	No impact
24	Clock Skew (-5 min) on Master	PASS	879	Minor dip
25	Full cluster kill (3 pods)	PASS	—	Recovery ~75s
26	Full MaxScale kill (3 pods)	PASS	955 after	~3 min client outage
27	Compound: Master + all MaxScale kill	PASS	—	Recovery ~90s
28	Rolling restart 0 → 1 → 2	PASS	—	Recovery ~2m30s

Key Findings

Galera vs Replication: Head-to-Head

Scenario	Galera TPS	Replication TPS	Winner	Why
Network Latency 1s	3	941	Replication	Async replication doesn’t wait for acknowledgment
Packet Corrupt 50%	0 (outage)	967	Replication	Galera needs valid certification packets
IO Latency 100ms	1450	5	Galera	Multi-master routes writes to healthy nodes
IO Fault (EIO) on Master	1404	~200 (dip then recovery)	Galera	Galera multi-master keeps writing on healthy nodes with no failover; Replication takes a short MaxScale failover hit before traffic resumes on the new Master
Bandwidth 1mbps	280	22	Galera	Multi-master distributes load
Pod Kill	1061	958	Tie	Both recover quickly
CPU Stress	1034	933	Tie	Both unaffected

When to Choose Each Topology

Choose Galera Cluster when:

IO-intensive workloads that benefit from multi-node write distribution
Environments needing true multi-master writes
Single-node failure should not block writes
Synchronous replication guarantees are required

Choose Replication + MaxScale when:

Networks with high latency or unreliable connections (WAN, cross-region)
Environments prone to packet corruption or packet loss
Read-heavy workloads where Slaves offload read traffic
Simpler operational model with clear Master/Slave roles

Conclusion

The KubeDB operator demonstrated excellent recovery capabilities across 46 chaos experiments on 2 MariaDB topologies — 18 on Galera Cluster (all PASS) and 28 on Replication with MaxScale (all PASS). All 46 experiments completed with zero data loss.

The operator handled every failure scenario we threw at it:

Operator Capability	What We Tested	Result
Failure detection	Pod kill, container kill, pod freeze, IO crash, segfault	Coordinator detected all failures within seconds
Automatic failover	Kill master/primary during active writes	New master elected, replication reconfigured, MaxScale re-routed — all automatically
Pod recovery	OOMKill, IO latency, read-only filesystem, clean pod kill	Crashed pods restarted, rejoined cluster via IST/SST, data fully restored
Cluster bootstrap	Kill all 3 pods simultaneously	Coordinator bootstrapped from scratch in ~3 min — identified most up-to-date node, elected master, rejoined others
Network resilience	Partition, latency, packet loss/corrupt/duplicate, bandwidth throttle, DNS error	Cluster stayed operational (or recovered automatically after chaos expired)
MaxScale integration	All 28 replication experiments via MaxScale proxy	MaxScale detected every topology change and re-routed traffic automatically
IO faults	IOChaos `fault` (EIO 50%) on master and slave, IOChaos `attrOverride` (read-only datadir), IO latency	mariadbd crash auto-recovered: MaxScale promoted a healthy Slave instantly, ex-Master rejoined as Slave once chaos cleared, checksums matched cluster-wide

The KubeDB operator is the reason these chaos tests pass. MariaDB itself doesn’t know how to bootstrap a Galera cluster from a total outage, elect a new replication master, or reconfigure MaxScale routing. The operator’s coordinator sidecar handles all of this — making KubeDB MariaDB truly self-healing on Kubernetes for the pod / stress / network / time fault families.

For the IO-chaos family, recovery from latency, read-only filesystems, clean pod kill, and EIO faults (master or slave) works automatically — no operator intervention required. Both topologies achieve production-grade reliability across every failure scenario we tested.

What Next?

Please try the latest release and give us your valuable feedback.

If you want to install KubeDB, please follow the installation instruction from here .
If you want to upgrade KubeDB from a previous version, please follow the upgrade instruction from here .

Support

To speak with us, please leave a message on our website .

To receive product announcements, follow us on Twitter .

If you have found a bug with KubeDB or want to request for new features, please file an issue .

KubeDB

KubeStash

Stash

KubeVault

Voyager

ConfigSyncer

RESOURCES

RECENT NEWS/BLOG

Chaos Engineering KubeDB MariaDB on Kubernetes, Testing Galera Cluster & Standard Replication Resilience

Overview

Why Chaos Testing?

Setup Guide

Step 1: Create a kind Cluster

Step 2: Install KubeDB

Step 3: Install Chaos Mesh

Step 4: Deploy MariaDB Galera Cluster

Test Environment

Create a High-Availability MariaDB Galera Cluster

Deploy sysbench Load Generator

Prepare sysbench Tables

Run sysbench During Chaos

Galera Cluster Key Concepts

Chaos Testing

Verify Cluster is Ready

Chaos#1: Kill a Pod

Chaos#2: OOMKill (Memory Stress)

Chaos#3: Network Partition

Chaos#4: IO Latency (100ms)

Chaos#5: Network Latency (1s)

Chaos#6: CPU Stress (98%)

Chaos#7: Packet Loss (30%)

Chaos#8: Full Cluster Kill

Chaos#9: DNS Error

Chaos#10: IO Fault (EIO 50%)

Chaos#11: Clock Skew (-5 min)

Chaos#12: Bandwidth Throttle (1 mbps)

Chaos#13: Pod Failure (5 min pause)

Chaos#14: Container Kill (mariadb process only)

Chaos#15: Packet Duplicate (50%)

Chaos#16: Packet Corrupt (50%)

Chaos#17: IO Attr Override (read-only filesystem)

Chaos#18: IO Mistake (random data corruption in IO)

MariaDB Replication with MaxScale (28 Experiments)

Replication Test Environment

Deploy MariaDB Replication with MaxScale

Standard Replication Chaos Experiments

Chaos#1: Pod Kill — Master

Chaos#2: Pod Kill — Slave

Chaos#3: Pod Kill — MaxScale

Chaos#4: Container Kill — mariadb on Master

Chaos#5: Pod Failure (90s freeze) — Master

Chaos#6: Memory Stress (1400MB) — Master

Chaos#7: Memory Stress (1400MB) — Slave

Chaos#8: CPU Stress (98%) — Master

Chaos#9: Combined Memory + CPU Stress — Master

Chaos#10: IO Latency (100ms) — Master

Chaos#11: IO Latency (100ms) — Slave

Chaos#12: IOChaos fault (EIO 50%) — Master

Chaos#13: IOChaos fault (EIO 50%) — Slave

Chaos#14: IO AttrOverride (read-only datadir) — Master

Chaos#15: Network Partition — Master ↔ Slaves

Chaos#16: Network Partition — Slave isolated

Chaos#17: Network Partition — MaxScale ↔ MariaDB

Chaos#18: Network Latency (1s) — Master ↔ Slaves

Chaos#19: Packet Loss (30%)

Chaos#20: Packet Duplicate (50%)

Chaos#21: Packet Corrupt (50%)

Chaos#22: Bandwidth 1 Mbps — Master

Chaos#23: DNS Error — Master

Chaos#24: Clock Skew (-5 min) — Master

Chaos#25: Full MariaDB Cluster Kill

Chaos#26: Full MaxScale Kill

Chaos#27: Compound — Master + all MaxScale kill

Chaos#28: Rolling Restart (0 → 1 → 2, rapid)

Chaos Testing Results Summary

Galera Cluster Results (18 experiments, baseline ~1039 TPS)

Replication + MaxScale Results (28 experiments, baseline ~926 TPS)

Key Findings

Galera vs Replication: Head-to-Head

When to Choose Each Topology

Chaos#4: Container Kill — `mariadb` on Master

Chaos#12: IOChaos `fault` (EIO 50%) — Master

Chaos#13: IOChaos `fault` (EIO 50%) — Slave
